GEMSTONE & MINERAL INSPECTION

Rock sample under natural light and Short Wave

Above sample under natural light and Short Wave. WIllemite (green) Calcite (red) Franklinite and Zincite (non fluorescent).
Credit Jonathan Stone.

UV Light can react with the chemicals of a mineral specimen and cause it to glow, called fluorescence. Color and intensity of the fluorescence can identifty many materials. Some minerals and gemstones will fluoresce under shortwave UV light and not fluoresce under longwave.

Relevant UV Lamp Models..

LOCATE PET URINE SOURCES...

The amber-colored pet urine is composed of protein metabolism waste products, with feline diets typically protein richer than dogs. The urine will glow in the dark using a blacklight (longwave UV light). Since the UV light is relatively weak, it works best to darken the room as much as possible.
Using lower wattage blacklights (4 watt) require being close to the inspection area with it as dark as possible.

Relevant UV Lamp Models..

RODENT CONTROL...

Detect rodent presence and contamination in warehouses, storerooms, etc. by using an ultraviolet lamp to search out and fluoresce rodent urine. Dry rodent urine glows a blue-white if fresh to a yellow-white if old when exposed to longwave ultraviolet light. Rodent hair glows blue-white and is easily identified on sacks or intermixed with food grains.

Relevant UV Lamp Models..

FORGERY ANALYSIS

Forgeries of bank notes, standard checks and travellers' checks are mainly printed on inferior bleached paper or photocopied. Forgeries will glow under UV light and bona fides will be completely dull. Many newer credit cards have an invisible imprint on the front. American Express uses "AMEX". If no imprint, the card is a forgery. Alterations of legal documents such as careful erasure or ink eradication and altering paper textures are detectable with UV light.

Relevant UV Lamp Models..

AUTOMOTIVE LEAK DETECTION

Using longwave UV light, you can identify oil leaks by different, easily distinguishable, fluorescent colors. Applies to all types of engine oil leaks plus differential, wheel bearing, air conditioning system and brake fluid leaks.

Details regarding procedure to trace different types of leaks are given on the manufacturer - UV Products website. See Ultraviolet/Lab Application Notes at http://www.uvp.com.

Using UV light in combination with leak detection dye in the refrigerant charge, see http://www.techshop-ets.com.

Relevant UV Lamp Models..

ARSON DETECTION

In arson detection, accelerants' fluorescent glow is greater when exposed longer to heat. Their evidence is not always visible as they are absorbed by the fire but UV light can expose them.

Volatile hydrocarbons such as gasoline, grease, paints and others fluoresce when exposed to UV, and can be seen as fragments of incendiary devices. Ambient light must be minimized for use of UV light at a fire scene.

Relevant UV Lamp Models..

CRIME SCENE INSPECTION

Illegal dumping can be tracked at night using UV light.

UV light is used to detect the presence of trace evidence in forensic investigations. Blood, urine, semen and saliva can present visible fluorescence.

Relevant UV Lamp Models..

ARTWORK INSPECTION

UV or black light reveals changes on the surface of objects as it causes specific fluorescence in materials depending on composition and age. UV fluorescence can show overpainting or retouching and identify types of stains.

One can detect repair in paintings and rugs using UV light, as differences can be seen between the chemical composition of newer inks, paints, and dyes and that of the originals.

Relevant UV Lamp Models..

Under UV, hard-to-see cracks in such as porcelain fluoresce brightly and hidden repairs are easily detected as most adhesives become visible.

ADMISSION / ACCESS OR CROWD CONTROL

In high-patronage clubs, amusement parks and swimming pools, applying quick drying readmission inks can be read easily by UV light. For beverage control, a portable, small UV light can slip in a pocket.

Relevant UV Lamp Models..
